| 모델명 |
IW-072 |
| 설치방법 |
Wall Mounted |
| 크기 |
1700W x 1170H x 110D mm |
| 67"W x 46"H x 4"D |
| 무게 |
14Kg / 31 lbs |
| 칠판크기 |
72 inches diagonal, 1515W x 1080Hmm / 60"W x 43"H |
| 유효크기 |
1400W x 1050 Hmm / 55"W x 41"H |
| 디지털기능 |
Ultrasonic and Infrared Transmitters |
| 센서 |
2 Ultrasonic Sensors ( above and below ), 2 Infrared Sensors |
| 데이터전송방법 |
Serial or USB |
| 칠판표면 |
Doubles as Whiteboard Sheet and Projection Screen |
| 필기도구 |
Stylus (Including signal transmission device |
| Pointer / maker switching |
| 4 colors of black, red, blue and green) |
| Poin Tech Eraser (Including signal transmission device |
| wide and narrow Eraser Pads) |
| 기능버튼 |
New Board |
| Board with tags |
| Printing of the Board |
| Maximization of the Board |
| Position setting of control panel |
| 표시등 |
Power supply / Connection |
| 전원공급 |
Supplied from computer through PS/2 or USB port by accessory cables |
| 액세서리 |
4 Wall Brackets |
| Stylus ( Black, Red, Blue, Green ) |
| PoinTech Pointer Insert |
| Dry-erase Markers ( Black, Red, Blue, Green ) |
| PoinTech Eraser |
| PoinTech Eraser Holder |
| PoinTech Serial Cable ( 5m / 16" ) |
| USB Adapter + Connecting Cable |
| PoinTech Control Panel Sheet |
| PoinTech CD-ROM |
| 1AAA Battery and 4 N-cell Batteries |
| 5 Pointer Insert Felts |
| User's Manual |
| Quick Start Guide |
PoinTech 특징
참가자는 당신과 회의 내용에만 집중합니다.
멀티미디어 강의실 및 전산교육장 시스템운영 특성
